MQ993R
| Purchase Code (Product Model) | MQ993R 9dBi Antenna |
|---|---|
| Electrical Performance | |
| Frequency Range | 902-928 MHz |
| Gain | 9dBi |
| Half-Power Beamwidth | Horizontal: 65° Vertical: 65° |
| VSWR | ≤1.3 |
| Impedance | 50 Ω |
| Polarization | Circular Polarization |
| Axial Ratio | ≤2 |
| Maximum Power | 50 W |
| Lightning Protection | DC Grounded |
| Mechanical Performance | |
| Connector | N-Female |
| Connector Position | Side Lead |
| Antenna Dimensions | 258×258×33.5 mm |
| Net Weight | 0.85 kg |
| Radiating Material | Aluminum |
| Radome Material | PC+ABS |
| Radome Color | White |
| Protection Rating | IP54/IP65 |
| Operating Temperature | -40～60 °C |
| Pole Diameter | φ40～φ50 mm |
